CLINOX POWER X2 s an electrochemical device for TIG/MIG weld cleaning, polishing, passivation and mar-king on stainless steel.
CLINOX POWER X2 deploys 1500W and 50A thanks to an innovative inverter technology more efficient and powerful. The patented blowing torch and the dynamic pump function ensure an intensive and continuous electrochemical process increasing the company productivity.

Included torches (CLINOX POWER X2):

• Automatic cleaning torch (4 m)
Main torch with integrated fluid feed for intensive, continuous cleaning and polishing of stainless steel welds.

• Manual cleaning torch
Compact torch for manual use, ideal for small or hard-to-reach welds.

• D&W torch (Drop & Work)
Ergonomic torch with automatic electrolyte dosing, ideal for repetitive work with consistent quality.

• Marking torch
For electrochemical marking of stainless steel using stencils, such as logos, serial numbers and CE markings.

Products

Article number
Description
Article number
336.POWERX223001
Description
Clinox power X2

Details

Mains Voltage
230 V - 50/60 Hz
Maximum primary power
1800 VA
Output current
0÷50 A
Output voltage
3÷30 V AC/DC
Output power
1500 W
Voltage regulation
3÷30 V (step 1 V)
Current regulation - Low
15 A
Current regulation - Mid
30 A
Current regulation - High
50 A
Tank capacity
1,8 liter
Dispensing rate
1÷3,6 l/h
Pump regulation
Dynamic
Manual
Automatic: 8 levels
Weight
16,5 kg
Dimensions (L x B x H)
543 x 228 x 315 mm
Torches
Blowing torch - L. 4 m
Small manual torch
D&W torch (Drop & Work)
Marking torch
Functions
Cleaning
Polishing
Marking

Parts

Article number
Description
Included
Reorderable
Article number
337.CLX800124
Description
Blowing torch, L: 4 m
Included
1 pc
Reorderable
1 pc
Article number
337.CLX501035
Description
Complete torch holder
Included
1 pc
Reorderable
1 pc
Article number
337.CLX000170
Description
Ground cable with clamp, L: 3 m, Ø10 mm²
Included
1 pc
Reorderable
1 pc
Article number
337.CLXTIG000156
Description
Standard tungsten insert, L: 22 mm
Included
1 pc
Reorderable
1 pc
Article number
337.CLXTIG002565.10
Description
Fast bond pad, 24 × 45 × 4 mm
Included
2 pcs
Reorderable
10 pcs
Article number
337.CLXTIG002580.10
Description
PTFE ring, 23 × 19 × 10 mm
Included
1 pc
Reorderable
10 pcs
Article number
337.CLXTIG000756
Description
Graphite insert, L: 45 mm
Included
1 pc
Reorderable
1 pc
Article number
337.CLXTIG002541.05
Description
Big bond pad, 46 × 90 × 3.5 mm
Included
1 pc
Reorderable
5 pcs
Article number
337.CLX002886
Description
FKM O-ring, Ø36.8 × 29.74 mm
Included
1 pc
Reorderable
1 pc
Article number
337.CLXTIGB030
Description
Torch brush adapter mod. PRO
Included
1 pc
Reorderable
1 pc
Article number
337.CLXTIGB045
Description
Clinox brush “XL”
Included
1 pc
Reorderable
5 pcs
Article number
337.CLXTIGB046
Description
PTFE sleeve (for Clinox brush XL)
Included
1 pc
Reorderable
5 pcs
Article number
337.CLXTIG002508.06
Description
Brill Bomar solution, 1 L (cleaning and polishing solution)
Included
1 pc
Reorderable
( 6 x 1 l )
Article number
337.ESXFIT000001.06
Description
Inox Fit, 500 ml (neutralizing solution)
Included
1 pc
Reorderable
( 6 x 1 l )
