Helvi hand cutting torch EP-126, 75°
Need help with this product?
You can call or mail us.
We will gladly help you!
,
Details
Cutting current
40-150 A
Duty cycle 60%
125 A
Duty cycle 40%
150 A
Gas supply
Air, Nitrogen
Gas supply pressure Cutting 125 A
5.0 - 6.0 Bar (72 – 87 Psi)
Gas supply pressure Cutting 150 A
5.5 - 6.0 Bar (80 – 87 Psi)
Gas supply pressure Gouging
3.5-4.5 Bar (50 – 65 Psi)
Ignition
Without High frequency
Products
Article number
Description
Cable
Article number 315.23010153
Description Helvi Plasma torch EP-126, H.Fit 75°
Cable 6 metres
Parts
Article number
Description
Drawing number
Article number
375.05900E
Description
hand torch head EP- 126 75°
Drawing number
1
Article number
375.03700.60
Description
O-ring
Drawing number
n/s
Article number
375.60042
Description
Swirl ring, 45-85 A maximum life
Drawing number
3
Article number
375.60040
Description
Swirl ring, 100-125 A maximum life
Drawing number
4
Article number
375.52677
Description
Electrode, 45-125 A
Drawing number
5
Article number
375.52677BM
Description
Electrode, 45-125 A, bimetal (on request)
Drawing number
Article number
375.51415
Description
Tip, cutting, 45 A, precision cut
Drawing number
6
Article number
375.51416
Description
Tip, contact cutting, 45 A
Drawing number
7
Article number
375.51417
Description
Tip, contact cutting, 65 A
Drawing number
Article number
375.51418
Description
Tip, contact cutting, 85 A
Drawing number
Article number
375.51419
Description
Tip, contact cutting, 105 A
Drawing number
8
Article number
375.51419.16
Description
Tip, contact cutting, 125 A
Drawing number
Article number
375.51419.18
Description
Tip, contact cutting, 150 A
Drawing number
Article number
375.60309AV
Description
Shield cup body, 45-85 A maximum life
Drawing number
9
Article number
375.60309BV
Description
Shield cup body, 100-125 A maximum life
Drawing number
10
Article number
375.60032
Description
Swirl ring, 45 A, precision cut, Maximum life
Drawing number
11
Article number
375. 51928
Description
Deflector,
Drawing number
12
Article number
375. 51931
Description
Deflector, 45 A, precision cut
Drawing number
13
Article number
375. 51921
Description
Shield cap, 45-85 A Hand
Drawing number
14
Article number
375.51926
Description
Shield cap, 100-125 A Hand
Drawing number
15
Article number
375.51417G
Description
Tip, gouging, 65-85 A
Drawing number
16
Article number
375.51418G
Description
Tip, gouging, 105 A
Drawing number
17
Article number
375. 52677L
Description
Extended electrode, 45-125 A
Drawing number
19
Article number
375.51417L.12
Description
Extended tip, 65 A
Drawing number
20
Article number
375.51417L.13
Description
Extended tip, 85 A
Drawing number
Article number
375.51417L.15
Description
Extended tip, 105 A
Drawing number
21
Article number
375.51417L.17
Description
Extended tip, 125 A
Drawing number
Article number
375.51923L
Description
Extended shield 65-125 A
Drawing number
22
Article number
375.51865
Description
Circle cutting attachment
Drawing number
n/s
Article number
375.51880
Description
Bevel tool
Drawing number
23
